Sensor: inductive; OUT: PNP / NO + NC; 0÷12mm; 10÷30VDC; M18; IP67 PEPPERL+FUCHS
Product Code: NBN12-18GM50-A2-V1
Brand
More similar products
Delivery terms
Product will be ordered from supplier. If the supplier is unable to deliver by the specified date, we will inform you by e-mail
 Not available | Supplier Warehouse |
Home delivery
Home delivery
After handing over the goods to the courier, we will inform you by e-mail.
Over €25.00 (Orders up to 1000 kgs) | For free |
To €25.00 (Orders up to 1000 kgs) | €4.50 |
Delivery to DPD pickup locations
Delivery to DPD pickup locations
After handing over the goods to the courier, we will notify you by e-mail. Free delivery for orders over 25€.
€3.50
Product description
Brand
Sensor: inductive; OUT: PNP / NO + NC; 0÷12mm; 10÷30VDC; M18; IP67 PEPPERL+FUCHS
Useful information
Specifications
Supplier product description
Sensor: inductive; OUT: PNP / NO + NC; 0÷12mm; 10÷30VDC; M18; IP67
Useful information
Supplier parameters
Product code
NBN12-18GM50-A2-V1
Brand
PEPPERL+FUCHS
Supplier's product code
NBN12-18GM50-A2-V1
Product ID
U-272360
#Promotion
maintenance_202308
Body material
brass
Body plating
nickel
Connection
connector M12
IP rating
IP67
Kind of forehead
non-embedded
Manufacturer
PEPPERL+FUCHS
Max. operating current
0.2A
Number of pins
4
Operating temperature
-25...70°C
Output configuration
PNP / NO + NC
Overall length
65mm
Range
0...12mm
Supply voltage
10...30V DC
Switch housing
M18
Switching frequency max
1kHz
Thread length
40mm
Type of sensor
inductive
