Microswitch SNAP ACTION; 0.05A/24VDC; SPST-NC; Rcont max: 100mΩ NKK SWITCHES
Product Code: CB315FP-R
Brand
More similar products
Delivery terms
2024-08-01 Estimated delivery
Product will be ordered from supplier. If the supplier is unable to deliver by the specified date, we will inform you by e-mail
 971 pcs | Supplier Warehouse |
Home delivery
Home delivery
After handing over the goods to the courier, we will inform you by e-mail.
Over €25.00 (Orders up to 1000 kgs) | For free |
To €25.00 (Orders up to 1000 kgs) | €4.50 |
Delivery to DPD pickup locations
Delivery to DPD pickup locations
After handing over the goods to the courier, we will notify you by e-mail. Free delivery for orders over 25€.
€3.50
Product description
Brand
Microswitch SNAP ACTION; 0.05A/24VDC; SPST-NC; Rcont max: 100mΩ NKK SWITCHES
Useful information
Specifications
Supplier product description
Microswitch SNAP ACTION; 0.05A/24VDC; SPST-NC; Rcont max: 100mΩ
Useful information
Supplier parameters
Product code
CB315FP-R
Body dimensions
6.2x6.2x3.1mm
Body material
stainless steel
Button shape
round
Contact material
brass
Contact plating
silver plated
Contacts configuration
SPST-NC
DC contacts rating @R
50mA / 24V DC
Electrical life
100000 cycles
Illumination
none
Key stroke
0.25mm
Leads
Gull Wing
Manufacturer
NKK SWITCHES
Manufacturer series
CB3
Max. contact resistance
:100mΩ
Mechanical durability
100000 cycles
Min. insulation resistance
0.1GΩ
Mounting
SMD
Number of positions
2
Number of terminals
4
Operating Force
1.57N
Operating temperature
-25...70°C
Poles number
1
Stable positions number
1
Switching method
OFF-(ON)
Terminal pitch
4mm
Type of switch
microswitch SNAP ACTION
Brand
NKK Nikkai
Supplier's product code
CB315FP-R
Product ID
U-2412660
The information that supplier provides may differ from the actual product. If you noticed an error please let us know by email: [email protected].
