Product description
Wireless Modbus for buildings - Installation Guide
W-Modbus for solar installations
W-Modbus DIN rail mount
The W-Modbus solution eliminates the need to run control cables for Modbus RTU installations significantly reducing time-consuming cable installations, installation planning, troubleshooting, and daisy-chaining.
- Connect 1 Modbus Clients to one W-Modbus
- Modbus compatibility – Compatible with all Modbus RTU devices
- Instant commissioning – 3 simple steps, commissioning the W-Modbus network in minutes.
- Mesh network – cover an entire building, utilizing the mesh network as your infrastructure.
- Range – 500 meters (line-of-sight) per hop in the mesh network.
- Cognitive Coexistence – LumenRadio’s patented technology provides industrial-grade reliability and immunity to interference.
- Self-optimizing network – the mesh network will always find the best way to send messages through the network between devices.
- Modular configuration – you no longer need to have the same baud rate in the whole network, supports individual settings for each device.
- Power supply: 24 VAC ±15% 50-60 Hz, 24 VDC ±15%
- Max. power consumption: 2.5 W
- 24 V output max. power: 10 W
- Auto resettable fuse: Yes
- Cable rating, connector: solid / stranded 0.14 – 0.5 mm2 / 0.2 – 0.5 mm2
- Conductor sizes (AWG) 24 – 20
- Frequency band: 2.45 GHz, ISM band (2400-2483 MHz)
- Baud rate: 9600, 19200, 38400, 76800 bps
- Stop bit: 1, 2
- Parity: none, even
- Number of Servers: 4 Servers to one W-Modbus PRO
- Number of hops: 8 hops in the meshing network
- Range per hop: 500 m line of sight (approximately 50- 70 m indoors with walls)
- Output (ERP): Max 20 dBm
- IP class: 40
- Material: ABS UL94-V0
- Colour: White, RAL 9003
- Ambient temperature: Operating: -20 to +55°C
- Storage: -30 to +80°C
- RH: 10 – 95% non-condensing
- Weight: 95g
- Dimensions: W86.0 x H86.0 x D25.5 mm
A W-Modbus network consists of a single W-Modbus Gateway connected to the Modbus Client using a Modbus RTU cable and up to 100 W-Modbus Nodes, each of them connected to one Modbus Server over a Modbus RTU cable. The W-Modbus network is built on LumenRadio’s MiraMesh, a self-forming and self-healing wireless mesh technology.
Useful information
Specifications
Experimental product description generated by artificial intelligence
W-Modbus DIN - Wireless Modbus Gateway
The LumenRadio W-Modbus DIN is a wireless communication solution designed for building automation systems. This reliable gateway allows you to connect your Modbus devices wirelessly, eliminating the need for extensive cabling.
Key Features and Benefits
- Wireless Modbus Communication: Enables seamless wireless connection of Modbus devices, reducing installation time and costs.
- Easy Installation: Simple setup and configuration, minimizing downtime and complexity.
- Retrofit Friendly: Ideal for modernizing existing building automation systems without major construction.
- Reliable Mesh Network: Provides robust and stable wireless communication across your building.
- Cost-Effective Solution: Reduces cabling expenses and installation time, leading to significant cost savings.
Applications
The W-Modbus DIN is perfect for various building automation applications, including:
- HVAC control
- Lighting management
- Security systems
- Access control
Why Choose LumenRadio W-Modbus DIN?
LumenRadio is a trusted provider of wireless solutions known for their reliability and performance. The W-Modbus DIN offers:
- Superior Wireless Performance: Ensures stable and consistent communication.
- Easy Integration: Works seamlessly with existing Modbus systems.
- Scalability: Supports a large number of devices.
- Robust Technology: Built with advanced mesh networking technology for reliable coverage.
Choose the LumenRadio W-Modbus DIN for a reliable, efficient, and cost-effective way to modernize your building automation system.
| Feature | Description |
|---|---|
| Product Name | W-Modbus DIN |
| Category | Wireless Communication Solutions |
| Brand | LumenRadio |
This description is generated using artificial intelligence (AI) and may differ from the actual product. Common AI errors may include:
- Inaccurate product features: some technical specifications, colors, sizes or other parameters may be inaccurate or omitted.
- Incorrect compatibility information: AI may provide incorrect information about the compatibility of products with other devices or systems.
- Overly Optimistic Functions: in some cases functions may be provided whose product iš doesnt really have.
- Name or Model Discrepancies: AI may misrepresent the product name or model.
If you notice inconsistencies or have questions about the description, please contact us before purchasing the product, please contact us by e-mail to you: aprasymai@lemona.lt.
