Rocker switch; ON-OFF, fixed, 2pins. 3A/250Vac, 19.4x7mm SPST, black
Product Code: R13-243A-02
Brand
More similar products
Pickup in department 1-5 b.d.
 >10 pcs | Central Warehouse |
 Not available | Tallinn Office |
Home delivery 1-5 b.d.
Delivery to DPD Pickup locations 1-5 b.d.
Products purchased together
Delivery terms
Pickup in department
Pickup in department For free
Orders are processed and shipped on weekdays from 8:00 a.m. to 5:00 p.m.
When your order is ready for collection, we will inform you by SMS and e-mail.
Quantity in shop
| >10 pcs | Central Warehouse |
| Not available | Tallinn Office |
Home delivery
Home delivery
After handing over the goods to the courier, we will inform you by e-mail.
Over €25.00 (Orders up to 1000 kgs) | For free |
To €25.00 (Orders up to 1000 kgs) | €4.50 |
Delivery to DPD pickup locations
Delivery to DPD pickup locations
After handing over the goods to the courier, we will notify you by e-mail. Free delivery for orders over 25€.
€3.50
Product description
Weight
0.00225 kg.
Brand
Montavimo kiaurymės išmatavimai 19.4 x 7 mm; AC 4 A / 250 V; kontaktai 4.8 x 0.8mm; max kontakto varža 50 mΩ; ilgaamžiškumas 6000 ciklų; degumo indeksas UL94V-2
Specifications
SKU
122946
Weight
0.00225 kg.
Fixation, 1-Su / 0-Be
With
Brand
Switch shape
Rectangle
Connection type
ON-OFF
Key color
Black
Contact configuration
SPST
Number of contacts
2
Body color
Black
Current, A
3
Type
Switch
Control voltage, V
250
Product code
R13-243A-02
Rated voltage AC, V
250
Supplier product description
ROCKER; SPST; Pos: 2; ON-OFF; 4A/250VAC; black; none; 50mΩ; UL94V-2
Supplier parameters
AC contacts rating @R
4A / 250V AC
Body colour
black
Body material
polyamide
Button marking
O-I
Contacts configuration
SPST
Electrical life
6000 cycles
Flammability rating
UL94V-2
Illumination
none
Key button colour
black
Leads
connectors 4,8x0,8mm
Manufacturer
SCI
Manufacturer series
R13-243-AC
Max. contact resistance
:50mΩ
Mounting hole diameter
19.4x7mm
Number of positions
2
Operating temperature
-20...80°C
Panel thickness
max. 3mm
Shape
rectangular
Stable positions number
2
Switching method
ON-OFF
Type of switch
ROCKER
The information that supplier provides may differ from the actual product. If you noticed an error please let us know by email: [email protected].
