Supplier product description
Relay: reed switch; SPST-NC; Ucoil: 5VDC; 3A; max.7kVDC; max.7kVAC
Useful information
Supplier parameters
Body dimensions
60x15.8x18.5mm
Coil resistance
38Ω
Coil voltage min.
3.7V DC
Contact current max.
3A
Contact material
tungsten
Contact resistance
250Ω
Contacts configuration
SPST-NC
Electrical life
10000000000 cycles
Insulation voltage
17kV
Manufacturer
SENSATA / CYNERGY3
Mounting
PCB
Operate time
2ms
Operating temperature
-20...70°C
Rated coil voltage
5V DC
Relay series
D
Release time
3ms
Switched voltage
max. 7kV AC
Type of relay
reed switch
Product code
DBT70510
Brand
SENSATA
Supplier's product code
DBT70510
Product ID
U-2218098
