Product description
Relay: electromagnetic; DPDT; Ucoil: 5VDC; Icontacts max: 5A; LM2 Recoy/RAYEX ELECTRONICS
Useful information
Specifications
Supplier product description
Relay: electromagnetic; DPDT; Ucoil: 5VDC; Icontacts max: 5A; LM2
Useful information
Supplier parameters
Product code
LM2-5D
Brand
Recoy/RAYEX ELECTRONICS
Supplier's product code
LM2-5D
Product ID
U-239529
AC contacts rating @R
5A / 250V AC
Body dimensions
29x15.5x12.5mm
Coil current
106.4mA
Coil power consumption
530mW
Coil resistance
47Ω
Contact current max.
5A
Contact material
AgCdO
Contact resistance
100mΩ
Contacts configuration
DPDT
DC contacts rating @R
5A / 30V DC
Manufacturer
Recoy/RAYEX ELECTRONICS
Mounting
PCB
Operate time
15ms
Operating temperature
-40...80°C
Rated coil voltage
5V DC
Relay series
LM2
Relay variant
miniature
Release time
10ms
Switched voltage
max. 30V DC
Terminal pitch
5mm
Type of relay
electromagnetic
