Product description
I/O MINI modules have been designed to complement the MIX series. Depending on the project needs, one of 7 different MINI can be chosen, all inputs and outputs are unified among our products. One feature that makes these two product groups different is hand operating switches, in some applications, it is required. Moreover, all I/O modules have BTL and UL certificates.
Like in the case of the MIX modules with RS485 and IP (1x Ethernet), MINI are factory-equipped with the most popular open communication protocols Modbus (ASCII, RTU, TCP/IP) and BACnet (MSTP, IP), which are selected using DIP switches. Rotary switches are used to set the module address, which facilitates and accelerates the process of commissioning the system. Built-in mini USB allows for the initial configuration of the unit without external power supply.
MINI I/O Modules with Ethernet have built-in Modbus Gateway TCP/IP to Modbus ASCII/RTU, enabling you to connect additional modules/devices that communicate via Modbus RS485.
Thanks to supporting open communication standards MINI modules can be installed in both new and completed installations, as part of existing BMS. This versatile device will fit any BMS perfectly.
Useful information
Specifications
Experimental product description generated by artificial intelligence
Expansion module iSMA-B-8U-IP
The iSMA-B-8U-IP expansion module from iSMA CONTROLLI is a versatile and reliable solution for various automation applications. This expansion module offers eight universal outputs, supporting Modbus TCP/IP and BACnet IP communication protocols.
Key Features and Functions
- Eight Universal Outputs: Provides flexibility for diverse control needs.
- Modbus TCP/IP and BACnet IP Communication: Seamless integration with existing building management systems (BMS).
- Universal Input Types: Supports voltage, current, resistance measurements, and dry contact.
Applications
The iSMA-B-8U-IP is ideal for a wide range of applications, including:
- Building automation
- Industrial automation
- Process control
- HVAC systems
Why Choose iSMA-B-8U-IP?
This expansion module offers a combination of features that make it a superior choice:
- Reliability: Built with high-quality components for long-lasting performance.
- Flexibility: Adaptable to various applications and communication protocols.
- Ease of Use: Simple integration and configuration.
- Cost-Effective: Provides a cost-effective solution for expanding your automation system.
| Feature | Description |
|---|---|
| Outputs | 8 Universal |
| Communication Protocols | Modbus TCP/IP, BACnet IP |
Expand your automation capabilities with the iSMA-B-8U-IP expansion module. Contact us today to learn more!
This description is generated using artificial intelligence (AI) and may differ from the actual product. Common AI errors may include:
- Inaccurate product features: some technical specifications, colors, sizes or other parameters may be inaccurate or omitted.
- Incorrect compatibility information: AI may provide incorrect information about the compatibility of products with other devices or systems.
- Overly Optimistic Functions: in some cases functions may be provided whose product iš doesnt really have.
- Name or Model Discrepancies: AI may misrepresent the product name or model.
If you notice inconsistencies or have questions about the description, please contact us before purchasing the product, please contact us by e-mail to you: [email protected].
