Handheld oscilloscope; 200MHz; 8bit; LCD 3,5"; Ch: 2; 1Gsps; 8kpts OWON
Product Code: HDS2202S
More similar products
Delivery terms
2024-08-14 Estimated delivery
Product will be ordered from supplier. If the supplier is unable to deliver by the specified date, we will inform you by e-mail
 55 pcs | Supplier Warehouse |
Home delivery
Home delivery
After handing over the goods to the courier, we will inform you by e-mail.
Over €25.00 (Orders up to 1000 kgs) | For free |
To €25.00 (Orders up to 1000 kgs) | €4.50 |
Delivery to DPD pickup locations
Delivery to DPD pickup locations
After handing over the goods to the courier, we will notify you by e-mail. Free delivery for orders over 25€.
€3.50
Product description
Handheld oscilloscope; 200MHz; 8bit; LCD 3,5"; Ch: 2; 1Gsps; 8kpts OWON
Specifications
SKU
U-3054086
Product code
HDS2202S
Supplier product description
Handheld oscilloscope; 200MHz; 8bit; LCD 3,5"; Ch: 2; 1Gsps; 8kpts
Supplier parameters
AC current measuring accuracy
±(1% + 10 digit)
AC current measuring range
10A
AC voltage measuring accuracy
±(0.8% + 10 digit)
AC voltage measuring range
750V
Additional functions
function generator
Band
200MHz
Capacitance measuring accuracy
±(3%+ 10 digit)
Capacitance measuring range
200µF
DC current measuring accuracy
±(0.8% + 10 digit)
DC current measuring range
10A
DC voltage measuring accuracy
±(0.3% + 5 digit)
DC voltage measuring range
1kV
Dimensions
198x96x38mm
Input coupling
AC, DC, GND
Input impedance
1MΩ/16pF
Kind of display used
LCD 3,5"
Manufacturer
OWON
Manufacturer series
HDS200
Measurement
AC voltage
Memory record length
8kpts
Number of channels
2
Power supply
rechargeable battery Li-Ion 18650 3,7V 2600mAh x2
Resistance measuring accuracy
±(0.8%+3 digit)
Resistance measuring range
200Ω
Rise time
≤1.75ns
Sampling
1Gsps
Standard equipment
case
Type of oscilloscope
handheld oscilloscope
Trigger modes
automatic
Vertical resolution
8bit
Waveform frequency range
0,1Hz...25MHz (sinus waveform)
Waveforms
rectangular
Product code
HDS2202S
Supplier's product code
HDS2202S
Product ID
U-3054086
The information that supplier provides may differ from the actual product. If you noticed an error please let us know by email: [email protected].
